Operating Parameters

1. Output : 0.3 to 7 cc/rev. per port
2. RPM    : 5-40
3. Number of Outlets : 3,4,5,6,8,10 or 12
4. Number of Levels : 1 or 2
5. Viscosity : 300 to 10000 poise
6. Inlet Pressure : 10 to 100 bar
7. Outlet Pressure:100 to 500 bar
8. Differential Pressure: 400 bar
9. Temperature: up to 350 oC
10. Cleaning Temperature: 500 oC

May also contact us in case of specific requirements and for replacement of existing installed pumps  or spares.


Catalogue : on request.
